Silni

« Prev Page(s): 1 2 Next »

General
YARDNUMBER	544803
IMO NUMBER	9424584
OWNER	Brodospas
MANAGER	Brodospas - Split
FLAG	CROATIA
DATE OF DELIVERY	January 2009
HULL MATERIAL	Aluminium
SUPERSCRUCTURE	Aluminium
BASIC FUNCTIONS	Fast supplier, crew boat
CLASSIFICATION	Bureau Veritas / CRS I HULL • MACH

Dimensions
LENGHT O.A.	35.95 m
BEAM O.A.	7.33 m
DEPTH AT SIDES	3.30 m
DRAUGHT AFT (APPROX.)	2.00 m
GROSS TONNAGE	168
NET TONNAGE	50

Capacities
FUEL OIL	28.00 m3
CARGO FRESH WATER	25.00 m3
WASTE WATER	0.50 m3
DIRTY OIL	0.50 m3
DECK TANKS	2 x 5.00 m3
PASSENGERS	30 persons
DECK SPACE	120.00 m2
DECK STRENGTH	1.4 t/m2

Performance
SPEED (TRIALS)	29 knots
OPERATIONAL SPEED	26 knots

Propulsion system
MAIN ENGINES	3 x Caterpillar x C32 C (WOSR)
TOTAL POWER	3132 bkW (4200bhp)@2100-2300rpm
GEARBOXES	3 x Reintjes WVS730
PROPELLERS	3 x Fixed pitch propellers

Electrical equipment
GENERATOR SET(S)	2 x 60 kW; 230V/400V 50Hz

Deck lay-out
ANCHOR	According to classification regulation
ANCHOR WINCH	Electrically operated
CRANE	1 x Effer 6000-1S (1t @ 5m)

Life saving equipment
LIFE BUOYS	4
LIFE JACKETS	40
LIFE RAFTS	2 x RDF 25 persons
FIRE MAN’S OUTFIT	2 x incl. 2 x fire axes
FAST RESCUE CRAFT	4,70 m MOB with outboard motor 25 hp
INTERNAL FIRE-FIGHTING	Fixed gas flooding system Engine Room Portable extinguishers according to class

Auxiliary systems
EXTERNAL FIRE-FIGHTING SYSTEM	1 x monitor 6000ltr/min
SPRAY BOOMS	82 litres seawater/min
SPRAY SHIELD ON DECK	Fitted around the hull at deck level
MECH. VENTILATION	Axial flow fans
BOWTHRUSTERS	1 x 75 kW, Hydraulic

Accommodation
OFFICERS CABIN	2 x 1 persons
CREW CABIN	2 x 2 persons
SUPERNUMERARIES SEATS	30
AIR-CONDITIONING	Air Conditioning in wheelhouse and accommodation
CREW	6 PERSONS
SUPERNUMERARIES	30 PERSONS

Nautical and Communication equipment
CALL SIGN.	9AA4565
SEARCHLIGHT	2 x 500 Watt
RADAR	2 x JRC JMA - 5106
MAGNETIC COMPASS	Ritchie HB 71
ECHO SOUNDER	Raymarine ST 40
GPS NAVIGATOR	JRC J-NAV 500
VHF	Sailor 2048 / Sailor RT 5022
HF/MF	Sailor HC 4500 B
PA/LOUDHAILlNG SYSYTEM	Alphatron Marine
SATCOM	NERA FLEET 33

General
YARDNUMBER	544803
IMO NUMBER	9424584
OWNER	Brodospas
MANAGER	Brodospas - Split
FLAG	CROATIA
DATE OF DELIVERY	January 2009
HULL MATERIAL	Aluminium
SUPERSCRUCTURE	Aluminium
BASIC FUNCTIONS	Fast supplier, crew boat
CLASSIFICATION	Bureau Veritas / CRS I HULL • MACH

Dimensions
LENGHT O.A.	35.95 m
BEAM O.A.	7.33 m
DEPTH AT SIDES	3.30 m
DRAUGHT AFT (APPROX.)	2.00 m
GROSS TONNAGE	168
NET TONNAGE	50

Capacities
FUEL OIL	28.00 m3
CARGO FRESH WATER	25.00 m3
WASTE WATER	0.50 m3
DIRTY OIL	0.50 m3
DECK TANKS	2 x 5.00 m3
PASSENGERS	30 persons
DECK SPACE	120.00 m2
DECK STRENGTH	1.4 t/m2

Performance
SPEED (TRIALS)	29 knots
OPERATIONAL SPEED	26 knots

Propulsion system
MAIN ENGINES	3 x Caterpillar x C32 C (WOSR)
TOTAL POWER	3132 bkW (4200bhp)@2100-2300rpm
GEARBOXES	3 x Reintjes WVS730
PROPELLERS	3 x Fixed pitch propellers

Electrical equipment
GENERATOR SET(S)	2 x 60 kW; 230V/400V 50Hz

Deck lay-out
ANCHOR	According to classification regulation
ANCHOR WINCH	Electrically operated
CRANE	1 x Effer 6000-1S (1t @ 5m)

Life saving equipment
LIFE BUOYS	4
LIFE JACKETS	40
LIFE RAFTS	2 x RDF 25 persons
FIRE MAN’S OUTFIT	2 x incl. 2 x fire axes
FAST RESCUE CRAFT	4,70 m MOB with outboard motor 25 hp
INTERNAL FIRE-FIGHTING	Fixed gas flooding system Engine Room Portable extinguishers according to class

Auxiliary systems
EXTERNAL FIRE-FIGHTING SYSTEM	1 x monitor 6000ltr/min
SPRAY BOOMS	82 litres seawater/min
SPRAY SHIELD ON DECK	Fitted around the hull at deck level
MECH. VENTILATION	Axial flow fans
BOWTHRUSTERS	1 x 75 kW, Hydraulic

Accommodation
OFFICERS CABIN	2 x 1 persons
CREW CABIN	2 x 2 persons
SUPERNUMERARIES SEATS	30
AIR-CONDITIONING	Air Conditioning in wheelhouse and accommodation
CREW	6 PERSONS
SUPERNUMERARIES	30 PERSONS

Nautical and Communication equipment
CALL SIGN.	9AA4565
SEARCHLIGHT	2 x 500 Watt
RADAR	2 x JRC JMA - 5106
MAGNETIC COMPASS	Ritchie HB 71
ECHO SOUNDER	Raymarine ST 40
GPS NAVIGATOR	JRC J-NAV 500
VHF	Sailor 2048 / Sailor RT 5022
HF/MF	Sailor HC 4500 B
PA/LOUDHAILlNG SYSYTEM	Alphatron Marine
SATCOM	NERA FLEET 33
