General
IMO NUMBER	8008967
FORMER NAME	"BALDER ADRIATIC". "BRITISH FORTIES", "BRODOSPAS 52"
OWNER	CROATIA SHIPPING LTD
MANAGER	BRODOSPAS - SPLIT
COUNTRY AND PORT OF. REG.	LUXEMBOURG
DELIVERED	1984
VESSEL BUILT	"TITOVO BRODOGRADILIŠTE" - KRALJEVICA
CLASSIFICATION	BUREAU VERITAS, CROATIAN REGISTER I HULL MACH Tug; Supply vessel; Oil Recovery Ship Unrestricted navigation AUT -UMS
NOBLE, DENTON ASSOCIATED LTD	YES

Dimensions
LENGHT O. A.	64,40 m
LENGHT ARTICLE 2 (8)	59,36 m
BREADTH MOULDED	13,80 m
DEPTH MOULDED	6,90 m
DRAFT	5,89 m
FREEBOARD	1011 mm
GROSS TONNAGE	1310
NET TONNAGE	607
DEADWEIGHT	1880 tons
SUEZ CANAL CERTIFICATE (YES/NO)	YES
DECK MEASUREMENTS	418 m2
DECK CARGO CAPACITY	740 tons
DECK STRENGHT - AFT PART	5 tons / m2

Towing - Anchorhandling
BOLLARD PULL	106 TONS MAX.
RIG CHAIN LOCKERS CAPACITY	117 m3
TOWING ANCHORHANDLING WINCH	"BRATTVAAG" SL 250 W/BSL 250 WX
No. OF DRUMS	TWO
DRUM CAPACITY, EACH DRUM	1400 m x 64 mm EACH
MIN. RATED PULL/BRAKE	250/350 TONS
EMERGENCY RELEASE OPERATE	YES
TOWING MAIN WIRE	1000 m x 64 mm
TOWING SPARE WIRE	1000 m x 64 mm
TOWING SHACKLES (No/TYPE/S WL)	28 CROSBY (SIZE: 25,35,55,85,110TONS)
TOWING QUICK RELEASE	FROM WHEELHOUSE; FROM DECK
TOWING PINS	ULSTEIN TWIN
TOWING GUIDE/GOG EYE TYPE	PAD EYE REMOVABLE
STERN ROLLER, DIAMETER	"ULSTEIN", 2200 mm
PENNANT WIRE/CHAIN STOPPERS	ULSTEIN VARIABLE INSERT

Deck equipment
ANCHORS
PORT ANCHOR TYPE: STOKES,	WEIGHT: 1750 kg, CABLE DIA: 34, CABLE LENGTH: 688
STARB. ANCHOR TYPE: STOKES,	WEIGHT: 1750 kg, CABLE DIA: 34, CABLE LENGTH: 688
SPARE ANCHOR TYPE: STOKES,	WEIGHT: 1740 kg
ANCHOR WINDLASS, MAKE	BRATITVAAG/B 12 - 54
CAPSTANS	BRATTVAAG/CM 4185, 5 TONS
TUGGER WINCHES (TYPE/S WL)	BRATTVAAG (WMA 1010/10 TONS)
RESCUE BOAT	No.: ONE TOTAL CAPACITY: 6 PERSONS
INFLATABLE LIFE RAFTS	No.: FIVE ; TOTAL CAPACITY: 4x20 ; 1x16 PERSONS

Tank capacities and discharge rates
POTABLE WATER CAPACITY	276 m3; 100 TONS / HOUR at 8 bar
DRILL WATER CAPACITY	800 m3; 160 TONS / HOUR at 8 bar
FUEL OIL CAPACITY -TOTAL	838 m3 INCLUDING MUD TANKS; 120 TONS / HOUR at 8 bar
BULK CEMENT TANKS	170 m3; 75/80 TONS / HOUR
LIQUID MUD CAPACITY	232 m3; 72 TONS / HOURS at 16 bar
RECOVERY OIL	88 m3

Propulsion system
MAIN ENGINES	JUGOTURBINA Sulzer TYPE: 16/25 ASV BORE: 250 mm, STROKE: 300 mm
POWER	kW: 2x3285 TOTAL kW: 6570
AUXILIARY ENGINE	SCANIA DSI 14M
GENERATORS	SG 2x800 kVA, DG 2x305 kVA
TOTAL GENER/ELEC. POWER	2210 kVA
VOLTAGE	440 V
FREQUENCY	60Hz
MAIN PROPELLERS	ULSTEIN TYPE: 2400 AGSC DIA.: 3000
NOZZLES - MAKE	ULSTEIN TYPE: FIXED
BOW THRUSTER No.	ONE, TOTAL kW: 584, TOTAL THRUST: 9,7 TONS; ULSTEIN TYPE: TV 150
SPEED/CONSUMPTION
MAX. CRUISING SPEED	17 KNOTS, CONSUMPTION: 33 TONS, RANGE: 26 DAYS
ECON. CRUISING SPEED	12 KNOTS, CONSUMPTION: 10 TONS, RANGE: 70 DAYS
INTEGRATED MANEUVRING SYSTEM	ULSTEIN TYPE: FCM SYSTEM

Firefighting
DECK Fi-Fi UNIT	Capacity 1200 m3/h at 11 bar

Nautical and communication equipment
CALL SIGN	LXBP
GMDSS	AREA A3
R/T (SSB) MAKE	Sailor HC - 4500
1x VHF	Sailor RT 4822
VHF/DSC	DEBEG 6348/3842
3 x VHF / GMDSS	TRON
2 x INM-C	T&T 3020 C
SAT. COM.	FLEET 33
SAT. COM.	MINI - M
MANOEUVRING CONTROL POSITION	TWO
1 x RADAR	FURUNO 8100 DA range 72NM
1 x RADAR	FURUNO FR-1500
GYROCOMPASS	ANSCHUTZ STD 12
MAGNETIC COMPASS	J.C.Krons and Son A.S. / 390
AUTOPILOT	Robertson / A 8
ECHOSOUNDER	Rpbertson / NJA-193S
SATELLITE NAVIGATOR	FURUNO GP 7000
1 x INTERNAL COM. SYSTEM	Phonico AS / PSA-2040
1 x INTERNAL COM. SYSTEM
EMERGENCY STEERING POSITION	FROM STEERING ROOM COMPARTMENT
VOICE COMM. - BRIDGE - ENM. STEERING	Phonico AS
VOICE COMM. - MAG.COMP. - STERREING	Talk Back System
VOICE COMM. - BRIDGE - ENG.ROOM	Phonico AS, Batt. Tel System / Talk Back System
PORTABLE VHF	2x MOTOROLA
NAVTEX	FURUNO NX-500
2xSART	TRON
EPIRB	JOTRON, TRON 40 GPS
AIS	FURUNO FA-100
LRIT	T&T

Accomodation
CREW	14 (26 TOTAL)
TOTAL No. OF SUPERNUMERARIES PERMITTED	12
CREW CABIN No.	10
SUPERNUMERARY CABINS	2
SUPERNUMERARY BERTHS	12
SHIP'S HOSPITAL, PERSONS	1

Other matrials / equipment
COMPLETE WORKSHOP WITH LATHE, DRILLING MACHINE, GRINDER ETC
GAS/OXYGEN AND ELECTRIC CUTIING/WELDING EQUIPMENT
