General
| IMO NUMBER |
8730560 |
| OWNER |
BRODOSPAS - SPLIT |
| MANAGER |
BRODOSPAS - SPLIT |
| COUNTRY AND PORT OF REGISTRATION |
CROATIA, SPLIT |
| VESSEL BUILT |
GOROKHOUETSKIY 1989 UKRAINA |
| CLASSIFICATION |
CROATIAN REGISTER |
Dimensions
| LENGHT OVER ALL |
29,3 m |
| LENGHT ON DESIGN WATERLINE |
28,2 m |
| LENGHT BETWEEN PERPENDICULARS |
27,0 m |
| BREADTH ON UPPER DECK |
8,3 m |
| BREADTH ON DESIGN WATERLINE |
8,2 m |
| DRAUGHT, MEAN, ON DESIGN WATERLINE |
3,2 m |
| DISPLACEMENT OF THE AFORESAID |
360 t |
| GROSS TONNAGE |
183 |
Speed and pull on hook
| Free running speed in deep sea at full displacement, with the state of sea to 2, is to 11,0 knots |
| BOLLARD PULL 23 TONS |
Tank capacities
| DIESEL OIL |
44,0 t |
| LUBRICATING OIL |
1,0 t |
| FEED WATER |
2.2 t |
| DRINKING AND WASHING WATER |
3,7 t |
The said stores of diesel oil and lubricating oil are to provide for the operation of
the main engines at speed for not less than 150 hours.
Arrangement of machinery installation
| MAIN ENGINE |
MAŠINSKI ZAVOD 25 OCTOBAR, CNP 25/34,
2x590 kW |
| GENERATOR |
1 SHAFT; 1 DIESEL |
