General
| IMO NUMBER |
8730560 |
| OWNER |
Brodospas |
| MANAGER |
Brodospas - Split |
| FLAG |
Croatia - Split |
| DELIVERED |
1989 |
| VESSEL BUILT |
Gorokhovets shipyard - Gorokhovets, Russia |
| CLASSIFICATION |
Croatian Register |
Dimensions
| LENGHT OVER ALL |
29.3 m |
| LENGHT ON DESIGN WATERLINE |
28.2 m |
| LENGHT BETWEEN PERPENDICULARS |
27.0 m |
| BREADTH ON UPPER DECK |
8.3 m |
| BREADTH ON DESIGN WATERLINE |
8.2 m |
| DRAUGHT, MEAN, ON DESIGN WATERLINE |
3.2 m |
| DISPLACEMENT OF THE AFORESAID |
360 t |
| GROSS TONNAGE |
183 t |
| NET TONNAGE |
57 t |
Speed, bollard pull
| TRIAL SPEED |
Free running speed in deep sea at full displacement, with the state of sea to 2 is to 11.0 kn |
| BOLLARD PULL |
23 t |
Tank capacities
| DIESEL OIL |
44.0 t |
| LUBRICATING OIL |
1.0 t |
| FEED WATER |
2.2 t |
| DRINKING AND WASHING WATER |
3.7 t |
The said stores of diesel oil and lubricating oil are to provide for the operation of
the main engines at speed for not less than 150 hours.
Fire-fighting system
| FIRE-FIGHTING EQUIPMENT |
Water fire-fighting - used as a fire electric pump capacity 25 m3/h; head 65 m w g. |
| |
Tank with foam agent capacity 0.5 m3. |
| |
Foam mixer. |
Arrangement of machinery installation
| MAIN ENGINE |
MAŠINSKI ZAVOD 25 OCTOBAR, CNP 25/34,
2x590 kW |
| GENERATOR |
1 SHAFT; 1 DIESEL |
